Bàn đo lực, 1308UH, Aikoh, Vertical type load testing stand
https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgDPQOpDJmUkN74qk_zvCKlvQDbsrWdpRIgvhDIrzCWovcCl2j5bQZNjuZTtLUYrA0brn5oEin7BXhrqb2OU5YDc7zOEsJ_Py-mAxO2aBM0x-qdrYyBN1uoJ2ott_r6UFNJ8XDic-YW2zU/s72-c/1308UH.jpg
Motorized stand high-speed type
MODEL-1308UH
High-speed type of MODEL-1308U.
Compliant with peeling test of JIS.
Example of use
Peel test
Specification
|
Name
|
MODEL-1308UH
|
|
Maximum load
|
200N (20kgf)
|
|
Controller
|
Built-in
|
|
Test speed
|
10 ~ 300mm / min
|
|
Speed switching
|
Volume
|
|
Stroke
|
400mm
|
|
Between the test center and the column
|
60mm
|
|
Size of table
|
W150 × D140mm
|
|
Drive motor
|
DC speed control motor
|
|
Size
|
W255 × H810 × D300mm
|
|
Stand mass
|
About 28Kgs
|
|
Power supply
|
Single-phase AC100 ~ 240V 0.5A
|
|
Options
|
Force gauge, jig, cable, Jig
mounting plate
OJ-P-90 and (at the time of tensile test)
|
